Description:
The 8-Pin Right-Angled Header is a single-row male connector designed for efficient PCB connections where space constraints necessitate a horizontal orientation. It features a 2.54mm (0.1″) pitch between pins, ensuring compatibility with standard PCB layouts and breadboards. The right-angle configuration facilitates parallel connections to the board surface, optimizing space and routing flexibility in compact electronic assemblies.
Constructed with durable materials, this header provides reliable electrical connections and mechanical stability. Its design supports straightforward soldering onto PCBs, making it ideal for various applications, including prototyping, custom PCBs, and interfacing modules. The pack includes five headers, offering ample components for multiple projects or replacements.
Specifications:
- Number of Pins: 8
- Pin Spacing (Pitch): 2.54mm (0.1″)
- Orientation: Right-Angle
- Row Configuration: Single Row
- Contact Material: Brass
- Contact Plating: Tin
- Insulator Material: Thermoplastic
- Current Rating: 3A
- Voltage Rating: 250V AC
- Operating Temperature Range: -40°C to +105°C
Features:
- Standard 2.54mm pitch compatible with common PCB designs
- Right-angle design for parallel board connections
- Durable construction with tin-plated brass contacts
- High current and voltage ratings suitable for various applications
- Pack of 5 headers for multiple projects
Contents:
- 5 x 8-Pin Right-Angled Headers
