Inductive Proximity PNP Sensor – LJ8A3-2-Z/BY

38 people have recently viewed this product!

Inductive Proximity PNP Sensor – LJ8A3-2-Z/BY

A high-performance M8 inductive proximity sensor PNP NC 2mm with a durable metal housing. Featuring a 10-30V DC operating range, 500Hz response frequency, and reverse polarity protection, it’s ideal for industrial automation, robotics, and fast-moving applications requiring precise metal object detection.

$21.95

Order Within –

Availability: 26 in stock

All stock located in Australia.

FREE SHIPPING Worldwide on orders $199+

EXPRESS SHIPPING Available.

SKU: PHI1002367

You May Also Like...

Description:

The M8 inductive proximity sensor PNP NC 2mm is a high-performance sensing solution designed for precision and durability. Operating on a 10-30V DC power supply, this industrial-grade sensor features a 2mm sensing range and a non-flush design, making it ideal for detecting metallic objects in automation and manufacturing applications. With a robust metal housing, it ensures reliable operation even in harsh environments.

This compact M8 proximity sensor offers a high-speed response frequency of 500Hz, enabling accurate detection in fast-moving systems. Built with reverse polarity protection and short circuit protection, it enhances safety and longevity in industrial setups. The PNP NC output configuration provides seamless integration with compatible control systems, ensuring smooth operation in automation processes.

Engineered for efficiency, this 2mm non-flush inductive sensor excels in applications requiring consistent and stable detection. Its rugged design and industrial-grade components make it a dependable choice for manufacturing, robotics, and assembly line operations where precise object detection is crucial.

Specifications:

  • Model: LJ8A3-2-Z/BY
  • Type: Inductive Proximity Sensor
  • Thread Size: M8
  • Output Type: PNP NC (Normally Closed)
  • Sensing Distance: 2mm (non-flush)
  • Operating Voltage: 10-30V DC
  • Response Frequency: 500Hz
  • Housing Material: Metal
  • Protection Features: Reverse Polarity Protection, Short Circuit Protection
  • Operating Temperature: -25°C to 70°C
  • Connection Type: 3-wire cable
  • Application: Industrial Automation, Manufacturing, Robotics

Features:

  • Compact M8 proximity sensor with a durable metal housing.
  • 2mm sensing distance with a non-flush mounting design.
  • PNP NC output for seamless integration with control systems.
  • Reliable 10-30V DC power operation with low power consumption.
  • High-speed 500Hz response frequency for fast-moving applications.
  • Reverse polarity and short circuit protection for enhanced safety.
  • Ideal for industrial automation, robotics, and assembly lines.

Contents:

  • Inductive Proximity Sensor LJ8A3-2-Z/BY
  • Pre-attached Cable
Weight 0.044 kg
Dimensions 120 × 20 × 80 mm
Brand

Type

Voltage

Current Rating

Detection Distance

Output Type

Output Configuration

Transistor Polarity

Frequency Response

Cable Length

Body Diameter

Operating Temperature
